Features
- Spotlight on Motion Detection
- Full-Color with Dual Smart Illumination
- Support Humanoid Detection
- Built-in Mic and Speaker
- With built-in PoE
- Equipped With unique VQC (Video Quality Catalyst) Technology
- Support 512GB SD Card
* * 01 Year Official Warranty
Description
Specifications
Video | |
Image Sensor | 1/3″ CMOS Sensor |
Max Resolution | 2560×1792 |
Effective Pixels | 5.0MP |
Compression Standard | H.264/H.265 |
Framerate | 25fps |
Bitrate | Main  Stream: 317Kbps ~ 8MbpsSub  Stream: 68Kbps~2728Kbps |
SNR (dB) | 52dB |
Min. Illumination | 0Lux  (light ON) |
Lens | |
Interface Type | M12 |
Lens | 2.8mm |
FOV | 2.8mm:H  96°, V 53°, D 110° |
Function | |
Audio Codec | G.711U/G.711A (default) |
Exposure Control | Auto |
White Balance | Auto |
Gain Control | Auto |
Digital 3D Noise  Reduction | Support |
OSD Information Setting | Large  font OSD, OSD flashing on alarm, OSD position settings |
SNTP | Support |
Schedule Reboot | Support |
Smart Defog | Support |
Motion Detection | Support Humanoid Detection |
Image Setting | Support Saturation, Brightness, Contrast, Sharpness  adjustment |
Image Style | Standard, Soft, Transparent |
Day and Night Function | Auto, Always Black & White, Always Color, Scheduled  Color |
Privacy Mask | Support up 8 areas |
Night Vision  Optimization | Support |
DWDR | Support |
Screen Settings | Screen mirroring, Screen flipping |
IP Adaptation | Support automatic adaptation of IP address (Optional) |
Intelligent  Analysis | Support Region Intrusion Detection, Line Crossing Detection,  Video Blocking Detection, People Counting |
Alarm Method | Email Alarm, Client Alarm |
Remote Operation | System, Audio and Video, Image, Alarm, Network management, Â Storage management, Intelligent Analysis |
Audio Function | Built-in Mic and Speaker |
SD Card | Support 512GB |
VQC Technology | Support |
Network | |
Ethernet | 10/100Mbps Ethernet |
Stream | 2x  Streams |
Network Protocols | HTTP, Â TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS |
ONVIF | Standard  ONVIF |
Network Transmission | CloudSEE 2.0 |
Browser | IE8+, Â Chrome18+, Firefox5.0+, Safari5.02+ |
User | Up  to 13 Users |
App | Support iOS/Android |
General | |
Lights | 2 Â White LEDs + 2 IR LEDs |
IR Distance | Up to 30 Meters |
Waterproof Level | IP67 |
Power Supply | DC12V or PoE (IEEE802.3af) |
Power Consumption | <4W Â (During Day); <6W (At Night) |
Working Temperature | -25°C ~ 55°C |
Working Humidity | 5% ~ 95% Rh |
Color/Material | White/Plastic+Metal |
Dimensions (WxHxD) | 106x94x106mm |
Weight | 320g |
Installation Method | Wall or ceiling mount |
